Spring Boot Neo4j Reactive CRUD.

spring boot

This article is about the spring data for neo4j database. Neo4j is a popular graph database.


Spring Data Neo4j module is there which is support only imperative style and currently, it’s only in support and maintenance.


You head this article that means you at least heard about Neo4j and spring boot. below are the prerequisites

  1. Neo4j (https://neo4j.com/graphacademy/online-training/introduction-to-neo4j-40/)
  2. Installation of Neo4j on local or use Neo4j sandbox.
  3. Knowledge with spring data and spring boot.
  4. For this example, we are using JDK 11.

If you don’t know anything about the above things then I will recommend you should start exploring these things and come back.

In this example, I am using Neo4j sandbox environment: https://neo4j.com/sandbox/

Advantages of using SDN-Rx:

  1. It supports both imperative and reactive development.
  2. Built-in OGM(Object graph mapping) and very lightweight.
  3. Support immutable entities for both Java and kotlin.

Maven/Gradle Dependencies:-

Right now Spring Data Neo4j Reactive starter is not yet part of the official Spring repositories so we have to add that manually, so it won’t be available in the spring initializer website.

## maven dependency
## gradle
dependencies {
    compile 'org.neo4j.springframework.data:spring-data-neo4j-rx-spring-boot-starter:1.1.1'

PrePare Database:-

For this article, we are using the Neo4j-standard movie graph database because it’s in small size and it’s available in your sandbox as well as in your local.

use this command to start:

:play movies

Execute the command and deck is an interactive mode, so its seamless execution. The movie database contains a database such as a movie name, release date, crew, director of movie, a rating is given by different individuals or rating companies. The minimal schema relation could be like this

(:Person {name})-[:ACTED_IN {roles}]->(:Movie {title,released})
movie DB schema

Create Project:

The best way to start with the spring boot project is start.spring.io. Create a spring boot project.

Do not choose Spring Data Neo4j here, as it will show the legacy generation of Spring Data Neo4j that has only imperative support.

Once your project is ready then add the spring data neo4j Rx dependency in your POM or build.gradle.


You can put here your database-specific configurations.


Domain Entity:

All our configurations are done now let us begin and define the domain entity object. As we stated we are using a movie database so we have to create Movie as a domain entity with few properties.

Entities are nodes.

package com.techwasti.entity;

import org.neo4j.springframework.data.core.schema.Id;
import org.neo4j.springframework.data.core.schema.Node;
import org.neo4j.springframework.data.core.schema.Property;
import org.neo4j.springframework.data.core.schema.Relationship;

import java.util.HashSet;
import java.util.Set;

import static org.neo4j.springframework.data.core.schema.Relationship.Direction.INCOMING;

public class Movie {

    private final String mtitle;

    private final String tagline;

    @Relationship(type = "ACTED_IN", direction = INCOMING)
    private Set<Person> actors = new HashSet<>();

    @Relationship(type = "DIRECTED", direction = INCOMING)
    private Set<Person> directors = new HashSet<>();

    public Movie(String title, String tagline) {
        this.mtitle = title;
        this.tagline = tagline;

    public String getTitle() {
        return mtitle;

    public String getTagline() {
        return tagline;
    public Set<Person> getActors() {
        return actors;

    public void setActors(Set<Person> actors) {
        this.actors = actors;

    public Set<Person> getDirectors() {
        return directors;

    public void setDirectors(Set<Person> directors) {
        this.directors = directors;

In the movie entity, we defined a movie name, tagline, actors, and directors.

@Node annotation marks the given class is the managed node. @Id annotation to have a unique property and then we defined different relationships using @Relationship annotation. In the same way, we have a Person entity that contains two fields.

package com.techwasti.entity;

import org.neo4j.springframework.data.core.schema.Id;
import org.neo4j.springframework.data.core.schema.Node;

public class Person {

    private final String name;

    private final Integer born;

    public Person(Integer born, String name) {
        this.born = born;
        this.name = name;

    public String getName() {
        return name;

    public Integer getBorn() {
        return born;

In these entities, we just defined one-way relation to have demonstrated things simple but you can also define an entity in such a way to fulfill two-way relationships.

Let us create a repository class then.

package com.techwasti.dao;

import com.techwasti.entity.Movie;
import org.neo4j.driver.internal.shaded.reactor.core.publisher.Mono;
import org.neo4j.springframework.data.repository.ReactiveNeo4jRepository;

public interface MovieRepository extends ReactiveNeo4jRepository<Movie, String> {
    Mono<Movie> findOneByTitle(String title);

This is to demonstrate the reactive programming style so we used here ReactiveNeo4jRepository which is reactive repository implementation.

You can hit below endpoints to see the output:

GET http://localhost:8080/movies

DELETE http://localhost:8080/movies/The Matrix

This is it for now.
